📹 Overview

The KN F24 4K Dashcam is a compact and reliable vehicle camera designed to capture clear footage while driving or when the vehicle is parked.

With 4K Ultra HD recording, WiFi connectivity, parking monitoring, and G-Sensor detection, the dashcam automatically records important road events and protects your vehicle.

Its compact design and 2.7-inch screen display allow easy viewing, playback, and settings adjustment directly from the device or via mobile application.

🎥 Video Recording

The KN F24 supports multiple resolution options depending on recording preference and storage capacity.

Resolution Options

• 4K Ultra HD – 3840 × 2144P
• 2K Recording
• 1080P Full HD

Higher resolutions provide clearer details such as:

✔ License plates
✔ Road signs
✔ Traffic incidents

🧠 Smart Recording Features

G-Sensor Impact Detection

The built-in G-Sensor detects sudden impact or collision and automatically locks the recorded video to prevent it from being overwritten.

Sensitivity Options:

• Close (Off)
• High
• Middle
• Low

Parking Monitor

The dashcam can monitor the vehicle while parked.

Options:

• Open
• Close

Compact Recording Mode (Time-Lapse)

Designed for long parking surveillance while saving storage space.

Available recording options:

• 1 FPS
• 2 FPS
• 5 FPS
• 8 Hours
• 12 Hours
• 24 Hours

📱 WiFi Connectivity

The KN F24 supports WLAN / WiFi connection allowing you to connect the dashcam to your smartphone.

Through the mobile app you can:

✔ View live camera footage
✔ Download recorded videos
✔ Adjust camera settings
✔ Manage storage

WiFi settings include:

• App connection
• WiFi password setup

⚙️ Camera & System Settings

The dashcam includes several customizable settings for better video recording and user control.

Display Settings

• Screen Brightness Adjustment
• Pull Mirror Back Function
• Screen Saver Options:

• 1 Minute

• 3 Minutes

• 5 Minutes

• Close

Audio Settings

• Sound Recording: On / Off
• Key Tone: On / Off
• Voice Broadcast: Open / Close

Image Settings

• Exposure Compensation
• White Balance Options:

• Automatic

• Sunlight

• Cloudy

• Tungsten Lamp

• Fluorescent Lamp

• Anti Flicker Setting:

• 50Hz

• 60Hz

Power & System Settings

• Auto Power Off:

• 1 Minute

• 3 Minutes

• 5 Minutes

• Time Settings
• Format Memory Card
• Restore Default Settings

System Version:

KN-F24-V1.0

🔌 Power Connection (Transverter Hardwire)

The KN F24 dashcam is powered using a transverter hardwire connection for stable voltage supply and cleaner installation.

Wiring Guide

Yellow Wire – Battery Power (Constant Power)
Red Wire – ACC / Ignition Power
Black Wire – Ground / Negative

This setup allows stable power supply and supports parking monitoring functionality.

Professional installation is recommended.

📏 Product Dimensions

Dashcam Body Size

Length: 8.7 cm
Height: 8.7 cm
Width: 3.8 cm

Screen Display

Display Size: 2.7 Inch

Full Screen Frame Size:

8.4 cm × 5 cm

📦 What’s Included

• KN F24 Dashcam Main Unit
• Power Cable with Transverter
• Mounting Accessories
• User Manual

(MicroSD card may depend on package variant.)

⚙️ TECHNICAL SPECIFICATIONS
